Large Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb Irbt

  • 1
  • 2
  • 3

Brand Name : YOUNGYOU

Model Number : YY-01-01-W2500-002

Certification : UL CE

Place of Origin : China

MOQ : 1

Price : 2000$/m

Payment Terms : L/C D/A

Supply Ability : 200SETS/MONTH

Delivery Time : 6-8 WEEKS

Packaging Details : Foam fixation/carton packaging/wooden box fixation

Load : 2500kg

Acceleration : 1500mm/m²

Running Speed : 100-1250mm/S（Adjustable

Reduction Ratio : 1:10（Adjustable

Robot Arm Spread : Within 2600mm

Overall Dimension : W=700mm/H=350mm/L=effective Stroke Plus 1500mm

Installation Mode : Horizontal Installation

Driving Mode(Driving Direction) : One Axis（Unidirectional Reciprocating）

Power Supply Conditions : Three Phase 380V±10/50HZ（We Can Supply Transformers）

Insulation Class : HP64

Guide Rail Weight (in Meters) : 350kg/m

Key words : Simple and fast

Contact Now

Stable and reliable guide rails in the field of mechanical processing. Simple and fast
Characteristics and advantages of high-precision linear guide rails
High precision: The high-precision linear guide adopts high-precision ball tracks and precise manufacturing processes, which can provide high-precision linear motion control and meet various high-precision machining and measurement applications.
High rigidity: The high-precision linear guide rail adopts high rigidity materials and design structures, which can provide good resistance to torsion and bending, ensuring the stability and accuracy of high-speed and high-precision motion.
High speed: The high-precision linear guide adopts optimized design and high-quality manufacturing process, which can provide high-speed linear motion control and is suitable for various applications that require high-speed motion.
Long service life: The high-precision linear guide rail adopts high-quality materials and precise manufacturing technology, which has good wear resistance and durability, ensuring long-term stable motion control and service life.

About the company

Our guide rail has cooperated with many international well-known robot brands, such as ABB KUKA FANUC Yaskawa UR. The companies involved mainly include palletizing, loading and unloading. The load of the guide rail ranges from 500kg to 5000kg. The length of the guide rail is customized according to the needs of customers. We have made a case that an ABB IRB6700 robot corresponds to 20 CNC machines, and a 50m long guide rail completes the reciprocating motion, loading and unloading of the robot. The number of robots is greatly reduced and the integration cost is saved.


Our company also offers industrial robots at very favorable prices to place orders together at lower prices.
Welcome to Shanghai, China, to investigate our robots and rails!


Company Product Supply.
ABB robot
KUKA robot
Yaskawa robot
Fanuc robot
UR robot
Cobot
Guide rail
Cobot made in China

NONameBrand/Specification
1Track bodyYOUNGYOU/W=700mm,H=350mm,L=As required by the buyer
2Planetary reducerSHIMPO Japan
3linear guide railHIWIN TaiWan HGH45
4Slide blockHIWIN TaiWan HGH45
5Rack and pinionChina TaiWan YCC Helical gear
6lubrication systemYOUNGYOU 1L
7Dust coverYOUNGYOU/Semi enclosed sheet metal type/Organ style
8Hard limit elastic bufferYOUNGYOU
9Robot mounting plateYOUNGYOU/1200*1000*30mm
10Ground connecting plateYOUNGYOU
11Drag chainKoduct/W=200mm,H=45mm,R250mm
12Reducer connecting flangeYOUNGYOU
13Servo motor①linkage Robot external axis
②Non linkage servo motor
14Adjusting boltM15 fine pitch thread
15Limit sensorJapan Omron





Large Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb IrbtLarge Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb Irbt
Large Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb Irbt
Large Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb IrbtLarge Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb IrbtLarge Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb IrbtLarge Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb Irbt



Packaging and Transportation
Large Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb Irbt
Large Heavy Duty Robot Tracks Guide Rails In Mechanical Processing Simple Fast Abb Irbt
