Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation

Product Categories
Shanghai YoungYou Intelligence Co.,Ltd.
Contact Now

Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation

Brand Name : YDobot

Model Number : EWR-YJ3

MOQ : 1

Price : Negotiate

Supply Ability : 200sets/Month

Packaging Details : Foam fixing + carton packing + wooden pallet fixing

Certification : CE UR

Place of Origin : CHINA

Control cabinet size : 360mm*160mm*402.4mm

Weight of control cabinet : 12kg

Number of control axes : 6 axis + external control axis

Output power : 48V,20A

Teaching method : Handheld teaching pendant / APP

Installation mode : Floor type

Environment : Temperature :0℃~45℃/Humidity:≤95%,No frost

Degree of protection : IP20

Key words : Handheld Teaching Pendant Industrial Robotic

Contact Now

Handheld Teaching Pendant Industrial Robotic Arm APP Operation Load 5KG

Collaborative robots, also known as cobots, are versatile machines designed to work alongside humans in a variety of applications. Some common applications of cobots include:
Assembly: Cobots can be used to assemble products in manufacturing environments, working alongside human workers to perform tasks such as screwing, bolting, or gluing.
Material handling: Cobots can be programmed to transport materials and products within a production line or warehouse, improving efficiency and reducing the risk of injury for human workers.
Quality control: Cobots can be used to inspect products for defects or damage, ensuring high-quality standards are met before the product is shipped.
Know more about our cobot and company
Company products supply
  • 400g load cobot
  • 3kg load cobot
  • 5kg load cobot
  • 7kg load cobot
  • 10kg load cobot
  • 15kg load cobot
ITEM DETAIL
Control cabinet size 360mm*160mm*402.4mm
Weight of control cabinet 12kg
Number of control axes 6 axis + external control axis
Input power Single phase electricity110V/220AC.7.5A,50/60HZ
Output power 48V,20A
Braking resistance 17W,10Ω,four
Communication interface EtherCAT(For external expansion shaft)Ethernet
IO interface 16 channel digital output
16 channel digital input / output(multiplexing)
2 analog outputs (0v-10v voltage) 4ma-12ma current
2 analog outputs (0v-10v voltage) 4ma-12ma current
1 channel ABZ incremental encoder input
Teaching method Handheld teaching pendant / APP
programing language script
BLOCKLY
Installation mode Floor type
Environment Temperature :0℃~45℃/Humidity:≤95%,No frost
Degree of protection IP20
Cooling mode Forced air cooling
Safety function Emergency stop function, reserved external safety interface (can be controlled through IO interface)
Indicator Status During normal power on, the red indicator light is always on; When the power is off, the indicator light goes out
Maintain Diagnostic software tools
Power off zero position protection function
Reserved remote service function

Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation

Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation
Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation
Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation
Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation
Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation
Transportation and Packaging
Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation
Universal Collaborative Robot Arm Load 5KG Handheld Teaching Pendant APP Operation
