Reach 900mm For Programming Contest Cobot In Food Production Facilities

Product Categories
Shanghai YoungYou Intelligence Co.,Ltd.
Contact Now

Reach 900mm For Programming Contest Cobot In Food Production Facilities

  • 1
  • 2
  • 3

Brand Name : dobot

Model Number : cr5

Certification : ul

Place of Origin : china

MOQ : 1

Supply Ability : 500sets/month

Packaging Details : carton ➕ Foam inner packaging, outer frame fixed by wood frame

Core Components : PLC, Motor

Weight : 25kg

Axis : 6 axis

Payload : 5kg

Reach : 900mm

Key Words : Programming Contest cobot in food production facilities

Contact Now

Reach 900mm For Programming Contest cobot in food production facilities

Robots can be widely used in electronic product workshops, auto parts workshops, pharmaceutical food workshops or business life scenes

Several well-known food production facilities have already adopted the use of cobots in their operations. One example is the Hershey Company, which implemented cobots for packaging chocolate bars. The cobots were equipped with specialized end-effectors to safely handle the delicate chocolate bars, reducing the risk of damage and waste.

Another example is Nestle, which used cobots for packaging pet food. The cobots were equipped with specialized end-effectors to handle the varied shapes and sizes of pet food products, ensuring efficient and accurate handling.

Know more about our cobot and company
Company products supply
  • 400g load cobot
  • 3kg load cobot
  • 5kg load cobot
  • 7kg load cobot
  • 10kg load cobot
  • 15kg load cobot
ITEM DETAIL
Control cabinet size 360mm*160mm*402.4mm
Weight of control cabinet 12kg
Number of control axes 6 axis + external control axis
Input power Single phase electricity110V/220AC.7.5A,50/60HZ
Output power 48V,20A
Braking resistance 17W,10Ω,four
Communication interface EtherCAT(For external expansion shaft)Ethernet
IO interface 16 channel digital output
16 channel digital input / output(multiplexing)
2 analog outputs (0v-10v voltage) 4ma-12ma current
2 analog outputs (0v-10v voltage) 4ma-12ma current
1 channel ABZ incremental encoder input
Teaching method Handheld teaching pendant / APP
programing language script
BLOCKLY
Installation mode Floor type
Environment Temperature :0℃~45℃/Humidity:≤95%,No frost
Degree of protection IP20
Cooling mode Forced air cooling
Safety function Emergency stop function, reserved external safety interface (can be controlled through IO interface)
Indicator Status During normal power on, the red indicator light is always on; When the power is off, the indicator light goes out
Maintain Diagnostic software tools
Power off zero position protection function
Reserved remote service function

Reach 900mm For Programming Contest Cobot In Food Production Facilities

Reach 900mm For Programming Contest Cobot In Food Production Facilities

Reach 900mm For Programming Contest Cobot In Food Production Facilities

Reach 900mm For Programming Contest Cobot In Food Production Facilities

Reach 900mm For Programming Contest Cobot In Food Production Facilities

Reach 900mm For Programming Contest Cobot In Food Production Facilities

Transportation and Packaging
Reach 900mm For Programming Contest Cobot In Food Production Facilities
Reach 900mm For Programming Contest Cobot In Food Production Facilities
